FA6 Series RISC Processors IP
原廠/品牌: 智原科技 上架日期: 05/20
供應商: 寅通科技 產品類別: Digital IP - Processor

     FA6 Series RISC Processors

     Faraday's FA626 is an ultra-high-speed general purpose 32-bit embedded RISC processor. It consists of a synthesized CPU core, an MMU, separate caches, scratchpads, and other units. The CPU core implements the ARM v4® architecture. Configurable features are available for the caches, scratchpads and write buffer. FA626 can operate at 533 MHz (worst case) with low power consumption. Faraday's FA626 is targeted for a wide range of applications, especially those requiring ultra-high performance, low cost, and low power consumption such as home entertainment, networking and office automation applications. The single-phase clock and standard-cell-based approach make it easy to integrate into any SoC design.

零件編號 封裝 規格說明 單價 庫存 最小量 購量
FA626TE Ultar-high-speed 32-bit ARMv5 RISC CPU       洽詢 4 週 1 洽詢
FA626 Ultar-high-speed 32-bit ARMv4 RISC CPU       洽詢 4 週 1 洽詢

With more and more functions and applications integrated into an embedded system, FA626 will open up new market applications for embedded SoC designs in favor of the ARM cores. FA626 delivers a CPU with the performance level of MIPS24K, PowerPC 440, and other high speed embedded CPUs, but with the popularity of the ARM architecture. Combining Faraday's solution-based IP and SoC expertise, we could deliver the optimal benefit to our customers to speed up their development cycle and shorten time to market.

The FA626 core consists of a synthesized 32-bit CPU core, an MMU, 32K I-Cache /32K D-Cache, separate configurable scratch pads ranging from 8 KB to 32 KB, and 8-stage pipeline architecture . This core is designed using the ARMv4™ instruction set and fully compliant with the ARM CPU cores and tool chains. It could operate at 533 MHz using UMC's 0.13 µm HS process under the worst case condition.

FA626 is suitable for a wide range of applications, especially those that require high performance, low cost, and low power consumption, such as PC peripherals, storage or networking applications.

FA626 RISC Processor Hard Core Configurations

Core Process
(µm)
I/D Cache Size*1 (KB) WC Freq.
(Mhz)
Typical Power
(mW/MHz)
Area
(mm2)
Availability (GDS)
GDSII Test Chip
FA626 0.13 HS 32/32*2 450 0.74 7.45 Now Now
0.13 HS 32/32 533 1.10 6.26 Now Soon
